Press the LOCK button on the keypad 1 time and listen to the beeps:.Make sure door is kept open during Function Test.
Manually unlock door lock and open the door. To check if a passcode has been successfully programmed in the memory: Press the Unlock Button on remote to confirm.įunction Test: If a passcode has not been successfully programmed, the lock will not operate using the keypad. Use keypad to enter an existing key code. During programing, the unlock button is used to confirm key codes being set or cleared. MILOCKS KEYPAD DOOR KNOB INSTALLATION CODE
Pressing the Unlock button after entering saved Keypad Code to electronically engage latch to unlock position. Lock Button: Electronically engages latch to lock position. Mi Logo Button (Top Button): Enables keypad back lighting.ġ-9, 0 Buttons: Used to enter numerical key codes. Switch needs to be OFF during any programming of codes. If Switch is on, toggles Auto Lock after 5-10 seconds in the unlock position, thumbturn will engage and lock automatically.
Programing Panelįound under battery cover of back module. ** Illustrations may not be exact representation of product.
Insert Drive Bar into Back Module's (B) Thumbturn Slot. (!) Before continuing: Drive bar should be oriented vertically and thumb turn should be oriented horizontally. Connect the White Wire Tabs from the Front Module (A) and back Module (B) together. Remove Battery Cover from Back Module before continuing:. Use Screws (F1) to secure Mounting plate and Front Module (A). Run Drive Bar and Wire Connector through Mounting Plate (D) as shown. (!) The top screw holes on Mounting Plate (D) should be angled away from door surface. On opposite side of door from front module: (!) Be sure drive bar is verticle when inserting through Latch. Run Connector Wire through bore hole of door. MILOCKS KEYPAD DOOR KNOB INSTALLATION INSTALL
(!) Install Latch and Strike Plate in a way where the lip from the plate and the angled slope from the latch meet, retracting the latch as door closes. Use Screws (F3) to secure Latch (E) To door.Use Screws (F3) to secure Strike Plate (C) to door frame.Just give us a call and we will take care of you.įor doors with bore holes 2 3/8" (60mm) from door edge, shorten latch by:įor doors with bore holes 2 3/4" (70mm) from door edge, extend latch by:
This keeps it on record with us so you don't have to save a receipt or record of any kind. ** Illustrations may not be exact representation of productĪlthough we hope you never have to deal with a warranty claim during the use of our product, you should submit a product registra on to validate the warranty.
Back Module ( B) needs to be protected from weather. Remove batteries from product when storing for extended periods of time. Only use brand new, popular brand, alkaline non rechargable AA batteries. Always have traditional keys on hand in case of electronic failure. Always use proper safety measures during the install of this product.
Carefully read instructions in their entirety before installing.
